• Assembly and commissioning through auto-learning
• World's smallest construction in discreet design
• Operation via app, Bluetooth and button
• Bluetooth Low Energy module for all switch types
• Low energy operating mode
• Currentless closing moment in the approach area
• Situational obstacle detection
• Replacement of hydraulic door closer by electronic system
• Sliding or scissor linkage
• DIN left and DIN right installation possible

• Drive dimensions 400 x 52 x 72 mm
• Low energy drive EN 16005
• Max. Opening speed/Full Power 40° per second
• Max. closing speed Closing speed/Full Power 40° per second
• Noise level < 30 dB
• Opening angle adjustable - max 115
• Range of slam function (de-energised) 0 - 15
• Motor damping of end stop 0 - 15°.
• Hold open time/Low Energy 2 - 60 seconds
• Hold-open time/Full Power 2 - 60 seconds
• Power supply external sensors 24 VDC / 0.8 A
• Power consumption Nominal power/standby 100 W / 1 W

The swing door drive can not only be operated via app. It is also suitable for any type of switch that is already in operation and without power. All you have to do is place our Bluetooth module behind the switch and connect it. The battery life is 8-10 years with normal use.

Bluetooth Smart - Clever and convenient

• Simplest operation via Bluetooth Smart
• Security through 128-bit encryption
• Battery-operated controls with 10-year lifetime
• Switching between operating modes
• Bluetooth module for all common push-buttons

The term LOW-ENERGY is not entirely new in the area of swing door automatics. This standard makes it possible to install an automatic system without special monitoring of the dangerous door and crushing edges of swing doors in such a way that there is virtually no risk of injury.

The low-energy operation is optimal for equipping handicapped-accessible flats in the entire interior with a swing door drive.

If no safety sensors are connected, the smartdoor TURN automatically switches to low energy mode and moves the swing door at reduced travel speeds in accordance with the safety requirements DIN 18650 and EN 16005.

The door drive must constantly monitor the speed so that the swing door never exceeds a maximum kinetic energy of 1.69J. This maximum kinetic energy is indicated in the door's power supply. This maximum kinetic energy is related to the door leaf mass and the door leaf width. This results in the maximum opening times.

The installation of the smartdoor TURN takes very little time.

• Fully automated commissioning
• Wide range of connection options
• Programmable output
• Ready for all sensors
• Patented pretension settings for the locking torque All mounting options in one model:
• DIN left or right | door leaf mounting | lintel mounting
• The pre-tension setting (locking torque) is supported by the control unit by moving the output drive to the correct position by motor and holding this position until the linkage is screwed tight.

User App

• Free App
• Installation guide
• Unlimited management of door operators
• Switching between operating modes
• Adjustment of the most important settings

Service tool

• Management of user rights
• Configuration of operator and peripherals
• Synchronisation and software update
• Preconfigured door types
• Management of unlimited number of doors
• Debugging, status display, error messages
